7. Centering of the control surfaces

Note: Before performing the following steps, please set the Top Gyro switch to EXPERT.
With the transmitter powered on, the battery connected to the controller and installed in the battery
compartment, you can now check the center of all control surfaces.
Observe the rudder to make sure it is properly centered as shown below.
Observe the elevator to make sure it is properly centered as shown below.
www.modster.at
Rudder surface not
0
centered correctly.
Rudder surface
1
centered correctly.
0
Rudder surface not
centered correctly.
1
Rudder surface
centered correctly.
0
0
1
0
0
1
