Table: POMPA MOT. RACC.
Ref. K Part n. Part n. 2
0089 RCDS39897
0090 RCDS01091
0091 RCDS40296
0092 RCDS40294
0093 LAFN40832
0093 LAFN40832
0094 RCDS21118
0095 RCDS21119
0096 RCDS40211
0097 VTRS00548
0098 RCDS00610
0099 TBAP40232
0100 TBAP40233
0101 RCVR62626
0102 RCIN09348
0103 MPVR40756
0104 VTRS00549
0105 GUVR40089
0106 GUGO27030
0107 RCDS72858
0108 RCVR40037
0109 VTRS00549
Date: 19/03/2020
Description
BLOCK 3VIE 3/8 F/F 1/2F
CAP 1/2X10 M
CONNECTOR G 3/8F -1/4 -P/NTC +M4 30
CONNECTOR G 3/8F -1/4 +d.15 TH C.25
PLUG "U" SIST.NTC PW-H INX
PLUG "U" SIST.NTC PW-H INX
CONNECTOR KSM
NUT KSM
SUMP PW-H28 D.15 OT.
WASHER D.17,5X23X1,5 (3/8)RM
NIPPLE 3/8 - 3/8 SV
HOSE-FITTING 3/ 8 R1 L=270 3/8F -3/8F
HOSE-FITTING 5/16 R1 L=540 3/8F -3/8M
SLEEVE 3/8 M/F L=30.5
MALE COUPLING 3/8MA L=32
TANK CAP KSM C/F.
WASHER D.21,5X27X1.5 (1/2) RM
ANTI-EXTR.RING D. 6.6X11.9X1.5 PTFE
O-RING D. 6 X 3 VIT 70SH
CONNECTOR VELOX 3/4"M
HOSE FITTING A.RP. - D.19 OTT.
WASHER D.21,5X27X1.5 (1/2) RM
Selected part: GNVA40051
Progressive number: 2
Validity
Quantity From
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
1,00
2,00
To Price
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
