b) Connecting speakers
Two cables are required to connect each speaker. Insulate all connecting terminals. Ensure there are no
sharp edges that may damage the cables.
Ensure that your speakers have a sufficiently high power rating (see "Technical data").
Connect the speakers directly to the amplifier. Do not use headphone adapters or distribution boxes. If you
are not sure how to connect your speakers, contact a specialist.
Check that all speakers are connected in the correct polarity (observe the plus and minus markings).
This amplifier has been designed for speakers with an impedance of 4-8 Ohms. Only connect one speaker
to each output.
You can connect banana plugs or stripped speaker wires (max. 2.5 mm in diameter).
If your speakers come with banana plugs, insert the plugs into the speaker connections on the amplifier.
To attach speaker wires, unscrew the clamps slightly and insert the stripped ends of each wire. Tighten the
clamps to secure the wires in place. To prevent a short circuit, ensure that the strands on the speaker wires
are fully inserted into the clamps.
Connecting the SPEAKERS connectors (14)
1
c) Connecting headphones
The device features a headphone jack
1. Insert the jack plug on your headphones into the headphone jack
2. If the jack plug does not fit into the headphone jack, use an adapter.
The speakers are automatically disabled when headphones are connected.
How to connect Connect to
R+ right speaker +
R- right speaker -
L+ left speaker +
L- left speaker -
(10) for connecting headphones.
(10).
