TNi PRO INSTALLATION LOUDSPEAKERS

WALL MOUNTED

All cabinets in the TNi-WPRO range have 4 x M8 mounting points for use with the HH wall bracket (sold separately):
TNi-BRK30-B - black finish
TNi-BRK30 - white finish
The wall mounting of cabinets should be performed only by properly qualified persons, in compliance with all local bylaws and
using approved hardware.
It is the installers responsibility to ensure the point of fixing is structurally adequate to support the weight of the cabinet.
For added safety, it is strongly recommended that the audio connections, mechanical fixing and mounting bracket are checked
periodically.
TNi-BK30 - MECHANICAL INFORMATION
LOUDSPEAKER PLATE
© 2022 HH Electronics Ltd
For increased safety, the M10 safety harness
fixing point (or one of the suspension point
fixings) should be used to make an additional
separately terminated fixing point.
107
Designed and Engineered in the UK by HH Electronics LTD.
iNSTALL
INSTALLATION
13.5
70
70
65
WALL PLATE
7
