TNi PRO INSTALLATION LOUDSPEAKERS
BADGE ROTATION
The HH badge is rotatable without the need for and any additional tools.
Gently grab the Badge and rotate to provide the desired orientation.
WAVEGUIDE ROTATION
To access the waveguide, the front grille must first be removed.
Carefully remove the eight screws indicated below.
Next remove the waveguide and set to required orientation.
Carefully re-assemble the cabinet.
© 2022 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
iNSTALL
INSTALLATION
THE HH LOGO INDICATES THE
BOTTOM OF THE WAVE GUIDE.
The TNi-WPRO range have their wave
guide set for use with the cabinet in a
vertical orientation, during the
manufacturing process.
