VLFS820-B2 INSTRUCTION MANUAL 中文文字说明请参见第 22 页 Texto en español, página 10 Deutscher Text Seiten 14 Svensk text sida 18 日本語は 24 ページ Texte français page 12 Nederlandse tekst op pagina 16 Русский текст: стр. 20 WE’RE HERE TO HELP Want to watch a video that Get it right the first time.
If your TV (plus accessories) weighs MORE, this (including accessories) mount is NOT compatible. 125 lbs. DO NOT EXCEED (56.6 kg) Visit SANUS.com or call customer service to find a compatible mount. Wall wood studs Solid concrete or CAUTION: Construction...
Dimensions BEFORE YOU BEGIN Remove the stand Install any accessories Protect the face from your TV — if attached. you may have purchased, if they requireTV of your TV when laying it down for removal prior to assembly. The TV is removable installation.
Seite 4
Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
Seite 5
STEP 1 Attach TV Brackets to TV 1.1 Select TV Screw Diameter 1.2 Select TV Screw Length and Spacers Only one screw size fits your TV. NO SPACER SPACER NEEDED • Flat Back TV • Flat Back TV • Rounded or Irregular Back TV with extra space needed [for deep inset holes or cable interference] [TV brackets NOT resting flat on your TV]...
Wood Stud Installation STEP 2A Attach Wall Plate CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1½ x 3½ in. (38 x 89 mm) ●...
Seite 7
Solid Concrete or Concrete Block Installation STEP 2B Attach Wall Plate CAUTION: Avoid potential personal injury or property damage! Concrete Anchors are not included ● Contact Customer Service: Mount wall plate directly onto concrete surface (no wall covering) US: 1-800-359-5520 ●...
Seite 8
STEP 3 Hang TV onto Wall Plate 3.1 Attach Arm Assembly to Wall Plate HEAVY! You may need assistance with this step. CAUTION: Avoid potential personal injury or property damage! For CONCRETE APPLICATIONS: The arm assembly MUST remain centered in wall plate NOTE: For WOOD STUD APPLICATIONS, the arm assembly can be...
Seite 9
Manage Cables IMPORTANT: Fully extend arm assembly ensure enough slack in cables. 2. Route your cables through the arm assembly shown. TV Adjustments TILT ADJUSTMENT Your TV should adjust easily when moved, then stay in place. If your TV is too loose or too tight use the hex key for additional tightening of the right and left tilt tension screws...
¿Su televisor pesa No — ¡Perfecto! (accesorios incluidos) 56,6 kg Sí — Este soporte NO es compatible. Visite MountFinder.Sanus.com o llame al : [US]: +1 (800)-359-5520 MÁS de 56,6 kg (125 lbs) (125 lbs)? [EMEA]: +31 (0) 495 580 852 [Reino Unido]: +44 (0) 800 056 2853 para encontrar un soporte compatible.
Seite 11
PASO 2A Cómo fijar la placa a la pared Colocación sobre montantes de madera PÁGINA 6 PRECAUCIÓN: Evite posibles lesiones personales o daños materiales. • • Los paneles de yeso que cubren la pared no deben superar los 1,5 cm (5/8 pulg.) Tamaño mínimo de los montantes de madera: nominal 5,1 x 10,2 cm (2 x 4 pulg.), real 3,8 x 8,9 •...
Avant de commencer, assurons-nous que ce support vous convient parfaitement ! Non — Parfait ! Votre téléviseur Oui — Ce support n'est PAS compatible. Visitez le site MountFinder.Sanus.com ou appelez le 56,6 kg (accessoires compris) [US]: +1 (800)-359-5520 [EMEA]: +31 (0) 495 580 852 [RU]:+44 (0) 800 056 2853pour trouver un support pèse-t-il PLUS de...
ÉTAPE 2A Fixation de la plaque murale au mur Installation sur des montants en bois PAGE 6 • • ATTENTION : Évitez les risques de blessures corporelles ou de dommages matériels ! L'épaisseur du revêtement de cloison sèche ne doit pas excéder 1,5 cm (5/8 po). Taille minimum des •...
Stellen Sie vor Montagebeginn sicher, dass diese Halterung für Sie geeignet ist! Wiegt Ihr Fernseher Nein – Perfekt! Ja – Diese Halterung ist NICHT kompatibel. Besuchen Sie MountFinder.Sanus.com oder rufen Sie die Nummer (einschließlich Zubehör) 56,6 kg MEHR als 56,6 kg [US]: +1 (800)-359-5520 [EMEA]: +31 (0) 495 580 852 [Vereinigtes Königreich]:+44 (0) 800 056 2853an, um...
Montage an Holzbalken SCHRITT 2A Anbringen der Wandplatte an der Wand SEITE 6 VORSICHT: Vermeiden Sie Verletzungen und Sachschäden! • • Die Gipsschicht der Wand darf 1,5 cm (5/8") nicht überschreiten. Mindestmaße der Holzbalken: Nenngröße 5,1 x 10,2 cm (2 x 4"), tatsächlich 3,8 x 8,9 cm (1½ x 3½"). •...
Controleer voor u begint of deze wandbevestiging ook voor u geschikt is! Weegt uw tv Nee: Prima! (inclusief accessoires) Ja: Deze wandbevestiging is NIET geschikt. Raadpleeg MountFinder.Sanus.com of bel 56,6 kg MEER dan [US]: +1 (800)-359-5520 [EMEA]: +31 (0) 495 580 852 [VK]:+44 (0) 800 056 2853 (125 lbs.)
Seite 17
Installatie met houten dragers STAP 2A Wandplaat aan de wand bevestigen PAGINA 6 LET OP: Voorkom lichamelijk letsel of materiële schade! • • Gipsplaten die de muur bedekken, mogen niet dikker zijn dan 1,5 cm (5/8 in.). Minimale grootte houten drager: nominaal 5,1 x 10,2 cm (2 x 4 in.), werkelijk 3,8 x 8,9 cm (1½ x 3½ in.). •...
Innan du börjar bör du se till att det här monteringsfästet är perfekt för dig! Nej – Perfekt! Väger TV:n (inklusive Ja – Det här monteringsfästet är INTE kompatibelt. Gå in på MountFinder.Sanus.com eller ring tillbehör) 56,6 kg MER än 56,6 kg [US]: +1 (800)-359-5520 [EMEA]: +31 (0) 495 580 852 [Storbritannien]:+44 (0) 800 056 2853 för att hitta...
Seite 19
STEG 2A Montera väggplatta på vägg Installation på träregel SIDAN 6 FÖRSIKTIGHET: Undvik eventuella personskador och materiella skador! • • Gipsskiva som täcker väggen får inte överstiga 1,5 cm (5/8 tum). Minsta storlek på träregel: nominell 5,1 x 10,2 cm (2 x 4 tum) effektiv 3,8 x 8,9 cm (1½ x 3½ tum). •...
(включая 56,6 кг принадлежности) Да — Это крепление НЕ подходит. Посетите веб-сайт MountFinder.Sanus.com или позвоните по телефону [US]: +1 (800)-359- весит больше чем (125 фунтов) 5520 [EMEA]: +31 (0) 495 580 852 [Великобритания]: 0800 056 2853, чтобы найти подходящее крепление.
Seite 21
ШАГ 2A Присоединение настенной пластины к стене Установка на деревянные стойки СТР. 6 ВНИМАНИЕ! Соблюдайте осторожность во избежание получения травм или повреждения имущества! • • Толщина гипсокартона, покрывающего стену, не должна превышать 1,5 см (5/8 дюйма). Минимальный размер деревянной стойки: общий 5,1 х 10,2 см (2 х 4 дюйма); номинальный 3,8 х 8,9 см (1 ½ x 3 ½ дюйма). •...
Seite 23
步骤 2A 木墙柱安装 将壁板安装到墙壁上 第 6 页 • • 注意: 墙上覆盖的干式墙不能超过 1.5 cm (5/8 in.)。 最小木墙柱尺寸:标称 5.1 x 10.2 cm (2 x 4 in.) 实际 3.8 x 8.9 cm (1½ x 3½ in.)。 避免潜在人身伤害或财产损毁! • • 扣件之间的最小水平间隔:40.6 cm (16 in.) 。 确保安装在墙柱中间...
