Disconnect the power tool from power supply.
● Pull the fixing sleeve (2) to the back and hold.
● Remove the working tool with your second hand by pulling it to the front.
OVERLOAD CLUTCH
Rotary hammer drill features overload clutch with factory setting. Spindle of the rotary hammer stops im-
mediately after working tool jams, what might overload the power tool.
Always use glasses or anti-splinter goggles, especially when drilling a hole above your head.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
The mains voltage must match the voltage on the rating plate of the rotary hammer drill.
Switching on – press the switch button (4) and hold in this position (fig. B).
Switching off – release pressure on the switch (4).
Locking the switch (continuous operation)
Switching on:
● Press the switch button (4) and hold in this position.
● Press the switch lock button (3).
● Release pressure on the switch button (4).
Switching off:
● Press and release the switch button (4).
Rotational speed of the spindle is controlled with pressure on the switch button (4).
OPERATION MODE SWITCH
Rotary hammer drill features 2-function switch of the working mode (5). Depending on its setting, a drilling
only or impact drilling is possible (fig. C).
Impact drilling requires to slightly press the rotary hammer. Too great pressure would cause unnecessary,
excessive load of the motor. Check technical condition of the working tools regularly. Sharpen or replace
working tools when needed.
● Pos0 = regular drilling
● Pos1 = impact drilling
Do not try to change position of the working mode switch when the motor of rotary hammer drill is
operating. Such action may lead to serious damage of the rotary hammer drill or even injury of the
user. Do not use three-jaw drill chuck, when the rotary hammer drill is set to impact drilling. This
chuck is designed for regular drilling only (in wood or steel).
LEFT – RIGHT DIRECTION OF ROTATION
Choose direction of rotary hammer drill spindle rotation with the selector switch (8).
Right rotation – set the switch (8) in the centreline of the switch (fig. B).
Left rotation – move the switch (8) to the extreme right position.
* The possibility is reserved that in certain cases position of the switch relating to rotation direction may be different than
specified. Please refer to graphic signs placed on the switch or tool body.
Do not change direction of rotation when the spindle of the rotary hammer drill is rotating. Ensure
the position of the selector switch is correct before starting the tool. Do not use left direction of
rotation when impact function is on.
DRILLING HOLES
● When drilling a hole with large diameter, it is recommended to drill smaller hole and then ream it to
desired diameter. It prevents overloading the rotary hammer drill.
