EN
1

DESCRIPTION

1.1

PURPOSE

The machine is used to propel air out of a tube to move
unwanted materials such as leaves in the yard. This machine
also sucks in leaves and small twigs through a vacuum, and
shreds them into a bag.
1.2

OVERVIEW

Figure 1 - 13.
Speed dial
1
Speed button
2
On/off button
3
Blower tube
4
Gate
5
Auxiliary handle
6
Vac tube
7
2

SAFETY

Make sure that you follow all safety instructions.
Refer to Safety Manual.
3

INSTALLATION

3.1

UNPACK THE MACHINE

Make sure that you correctly assemble the machine before
use.
• If parts of the machine are damaged, do not use the
machine.
• If you do not have all the parts, do not operate the
machine.
• If parts are damaged or missing, contact the service
center.
1. Open the package.
2. Read the documentation provided in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in compliance with
local regulations.
3.2

ASSEMBLE AS A VAC

Figure 2 - 8.
Collection bag
8
Lock button
9
10 Slot
11 Notched area
12 Nozzle
13 Battery release button
WARNING
WARNING
WARNING
English
Make sure that the machine is in the OFF position, and the
impellers stop before you attach or remove tubes.
1. Move the front and rear vac tubes together until the lock
button engages. (Figure 2)
2. Pull the lock button forward to disengage the gate.
(Figure 3)
3. Hold the gate open.
4. Put the "wedged" end clip of the vac tube into the rear
clip. (Figure 4)
5. Push the "hooked" end clip of the vac tube into the front
clip. (Figure 5)
6. Push back the lock button to engage the vac tubes.
(Figure 6-7)
You can do the steps above in the opposite sequence to
remove the vac tubes.
7. Put the bag adaptor into the blower outlet. Lock the bag
securely on the locking area. (Figure 8)
It can be necessary to remove the blower tube or vac tubes
to clean a blocked tube or impeller.
3.3

ASSEMBLE AS A BLOWER

Figure 9.
1. Insert the nozzle into the blower tube from the top and let
it slide down to the bottom.
2. Pull the nozzle to lock in its final position.
3. Push the blow tube on the notched area of the main unit
until the slot of the tube is locked on the notched area.
You can use the nozzle to increase airflow in tight areas:
flower beds, under decks, etc.
3.4

INSTALL THE BATTERY PACKS

Figure 10.
• If the battery pack or charger is damaged, replace the
battery pack or the charger.
• Stop the machine and wait until the engine stops before
you install or remove the battery packs.
• Use only 24V battery packs. Do not use dual-voltage
24/48V battery packs.
• Both battery packs should be installed into the
compartments in order to start the machine.
1. Align the lift ribs on the battery pack with the grooves in
the battery compartment.
4
WARNING
TIP
NOTE
NOTE
WARNING
