Do not cover or modify the lance or the spray
nozzles in any way.
•
The pressure cleaner is designed to be used
with cold or lukewarm water (max. 60 °C); hig-
her temperatures can damage the pump.
•
Do not use water that is dirty, gritty or con-
tains any chemical products, as these could
impair operation and shorten the life of the
equipment.
Caution: Risk of explosion
Do not spray fl ammable liquids.
Warning
Water that has passed through the non-return
valve is not drinkable.
Warning
If cleaning agent gets into contact with your skin
or into your eye, rinse immediately with lots of
clean water. Then consult a doctor or follow the
steps described on the safety data sheet or provi-
ded by the manufacturer of the cleaning agent.
5.2 Assembly
5.2.1 Assembling the equipment (Fig. 1)
Push the accessories holder (2) onto the high-
pressure cleaner (5). The holder can be used for
space-saving storage of the gun (8), the extensi-
on (9) and the high-pressure hose (15).
Note! Before using the pressure cleaner, make
sure that the high-pressure hose is completely
unwound.
5.2.2 Fitting the attachments (Fig. 2)
Before you use the high-pressure cleaner (5) you
must fi rst fasten the extension (9) to the gun (8)
by pushing and twisting.
Then push the rotating nozzle (13) or the cleaning
agent container (10) onto the extension (9) by
means of the quick connection system.
Rotating nozzle
To remove particularly stubborn dirt, use the rota-
ting nozzle (13).
Solid cone / fl at fan lance (14)
The shape of the water jet can be changed from
solid cone to fl at fan by turning the nozzle (Fig. 8).
Anl_TC_HP_2042_PC_SPK7.indb 19 Anl_TC_HP_2042_PC_SPK7.indb 19
GB
Cleaning agent container
You can adjust the quantity of cleaning agent you
want to add by turning (+ / -) on the setting wheel
(11). We recommend using the cleaning agent
sparingly.
5.2.3 Fitting the handle (Fig. 5)
Push the handle (1) onto the pressure washer (5)
and secure it using the 4 screws (long thread).
5.2.4 Assembling the terrace cleaner (Figs.
6-9)
Insert the extension for the terrace cleaner (16)
into the recess provided.
Then turn the terrace cleaner (16) over and insert
the two screws (short thread). Then place the
rotor (17) on the terrace cleaner (16) and secure
this by inserting the clip.
You can then attach the terrace cleaner (16) to
the extension (8) using the quick-lock system
(12).
5.2.5 Connecting the high-pressure hose
(Fig. 3/4)
Connect the high-pressure hose (15) to the gun
(8) and the high-pressure cleaner (5).
Note:
The connections for the high-pressure hose
and the accessories are equipped with a quick
connection system (12). To connect, simply push
the hose or the accessory onto the respective
connection. To remove, simply actuate the quick
connection system (12) and you can remove the
hose or the accessory.
Each time before fi tting, always check that the
quick connection system (12) is correctly enga-
ged. Do this by pulling briefl y on the hose or the
accessory.
5.2.6 Water inlet connector (Fig. 1/4)
The connection for the water inlet (4) is equipped
with a connector for standard hose coupling sys-
tems. Plug the hose coupling on the supply hose
(min. Ø 1/2") to the water inlet connector (4).
Always use a reinforced hose with a standard
coupling for the water inlet. The hose should be at
least 6 m in length. (Not supplied)
A backfl ow preventer must be installed between
the drinking water and the pressure cleaner! Ask
your local plumber about this.
