technische DAten

Maximale tiefe
sendeleistung
geberfrequenz
sendekegel
sendekegel
sendekegel
Benötigte spannung
lcD Anzeige
geber
Kabellänge geber
600 ft (185 m) – (PMAX150/160)
800 ft (250 m) – (PMAX170/180/190c)
800Watts (PtP) – (PMAX150/160)
1600Watts (PtP) – (PMAX170/180/190c)
200 khz single Beam (PMAX150/190c)
200 khz and 83 khz Dual Beam™
(PMAX160/170)
200 khz and 455 khz tri Beam
(PMAX180 only)
(PMAX150/190c)
20°@-10 dB in 200 khz
(PMAX160/170)
60°@-10 dB in 83 khz
20°@-10 dB in 200 khz
20°@-10 dB in 200 khz
90°total coverage (two 35° Beams)
160 V x 128 h – (PMAX150/160)
240 V x 160 h – (PMAX170/180)
320 V x 240 h – (PMAX190c)
(PMAX150/160/170/190c)
Xnt-9-qB-90-t – (PMAX180)
(PMAX180)
@-10 dB in
455 khz
10-20 VDc
Xnt-9-20-t –
20 ft (6 m)
