2. Attached documents
Recommended separation distances between portable and mobile RF communications
equipment and the CGM MB-1901.
The CGM MB-1901 is intended for use in an electromagnetic environment in which radiated
RF disturbances are controlled. The user of the CGM MB-1901 can help prevent electromagnetic
interference by maintaining a minimum distance between portable and mobile RF communications
equipment(transmitters) and the CGM MB-1901 as recommended below, according to the
maximum output power of the communications equipment.
Rated maximum output Separtaion distance (m) according to frequency of transmitter
power (W) of
150 kHz to 80 MHz
transmitter
0.01 0.12
0.1 0.37
1 1.17
10 3.70
100 11.70
For transmitters rated at a maximum output power not listed above, the recommended separation
distance (d) in meters (m) can be estimated using the equation applicable to the frequency of
the transmitter, where P is the maximum output power rating of the transmitter in watts (W)
according to the transmitter manufacturer.
Note 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected
by absorption and reflection from structures, objects, and people.
Immunity and Compliance Level
Immunity test IEC 60601 test level
Conducted RF
3 Vrms , 150 kHz to 80 MHz
IEC 61000 -4-6
Radiated RF
10 V/m, 80 MHz to 2.5 GHz
IEC 61000 -4-3
50
80 MHz to 800 MHz 800 MHz to 2.7 GHz
0.04 0.07
0.11 0.22
0.35 0.70
1.11 2.21
3.50 7.00
Actual immunity level Compliance level
3 Vrms , 150 kHz to 80 MHz 3 Vrms , 150 kHz to 80 MHz
3 V/m, 80 MHz to 2.7 GHz 3 V/m, 80 MHz to 2.7 GHz
2. Attached documents
Manufacturer's declaration - electromagnetic immunity
The CGM MB-1901 is intended for use in the electromagnetic environment specified below.
The customer or the user of CGM MB-1901 should assure that it is used is such an environment.
IEC 60601
Immunity test Compliance level
Test level
Conducted 3 Vrms 3 Vrms
RF 150 kHz to 80 150 kHz to 80
IEC 61000-4-6 MHz MHz
Radiated 3 V/m 3 V/m
RF 80.0 MHz to 2.7 80.0 MHz to 2.7
IEC 61000-4-3 GHz GHz
Note 1) These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
Note 2) It is essential that the actual shielding effectiveness and filter attenuation of the shielded location be
verified to assure that they meet the minimum specification.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically
with accuracy.
To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should
be considered. If the measured field strength in the location in which the EUT is used exceeds the applicable
RF compliance level above, the EUT should be observed to verifynormal operation. If abnormal performance is
observed, additional measures may be necessary, such as re-orienting or relocating the EUT.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than [V 1] V/m.
Electromagnetic
environment - guidance
CGM MB-1901 must be used only in a
shielded location with a minimum
RF shielding effectiveness and, for each
cable that enters the shielded location
with a minimum RF shielding
effectiveness and, for each cable that
enters the shielded location.
Field strengths outside the shielded
location from fixed RF transmitters, as
determined by an electromagnetic
site survey, should be less than 10V/m.a
Interference may occur in the vicinity of
equipment marked with the
following symbol:
