12. Technical data

12.1. Complete devices
ATTENTION!
Heavy shipping weight.
Designa- Stone
tion pack-
ages
6 x Kolli
VFE 20 K HFR 220
VFR
9 x Kolli
VFE 30 K HFR 330
VFR
12 x Kolli
VFE 40 K HFR 440
VFR
15 x Kolli
VFE 50 K HFR 550
VFR
18 x Kolli
VFE 60 K HFR 660
VFR
21 x Kolli
VFE 70 K HFR 770
VFR
12.2. Rating plate (right side panel)
The most important symbols on the rating plate are
explained below.
Loading voltage
Continuous voltage
Fan
Weight
EN-26
Heating Nominal
element output
set
400 V, 3 N~
2000 W
50 Hz
400 V, 3 N~
3000 W
50 Hz
400 V, 3 N~
4000 W
50 Hz
400 V, 3 N~
5000 W
50 Hz
400 V, 3 N~
6000 W
50 Hz
400 V, 3 N~
7000 W
50 Hz
E-Nr.:
VFE40
400V, 3N~, 50Hz
Ladedauer
4,0 kW
Nennleistung
Ladung 32 kWh
230V, 50Hz
230 kg
300000031
Made in the U.K. by Glen Dimplex UK Limited.
Glen Dimplex Deutschland GmbH. Am Goldenen Feld 18. 95326 Kulmbach
Nominal Nominal
voltage charging
16 kWh
24 kWh
32 kWh
40 kWh
48 kWh
56 kWh
Typ:
( )
FD 0009 000052U
01
8 h
GDID : 000000000000
15 W
PIN : 000000
IP21
UI/CC:
08/05/05
2202/D
Weight Transport
weight
622 x 664 x 250
127 kg 38 kg
mm
772 x 664 x 250
180 kg 44 kg
mm
922 x 664 x 250
230 kg 50 kg
mm
1072 x 664 x
281 kg 56 kg
250 mm
1222 x 664 x
331 kg 62 kg
250 mm
1372 x 664 x
383 kg 68 kg
250 mm
VFE40
