62
10
TECHNICAL DATA
Technical data
Connection nominal diameter
Nominal pressure
Nominal flow
Pressure drop at nominal flow
Water and ambient temperature
Dimensions (width x height x depth)
Adjustable limit value
Starting value
Miscellaneous functions
Electrical connection
Power consumption
Degree of protection
11
ACCESSORIES
/
Humidity sensor (order no. CLEARFS)
/
CLEAR BOX (order no. CLEARBOX)
/
Intermediate flange for installing the leak protection system in vertical pipes (order no. 1420043)
CLEAR STOP
DN 25 / 1"
PN 16
4 m³/h
0.5 bar
max. 30 °C
203 x 141 x 143 mm
/
max. volume drawn 0.1 to 3 m³
/
max. volume flow rate 10 to 100 l/min
/
max. drawing time 10 min to 2 h
12 to 15 l/h
/
Emergency on function
/
Holiday mode (adjustable)
/
Sleep mode (limit values switched off)
230 V / 50 Hz
1 W (10 W during opening/closing)
IP22
