5.3

POWER SUPPLY

A splash-proof socket, complying with the legal regulations for wet areas, is re-
quired for the power supply unit of the leak protection system and must be posi-
tioned above the filter at a separation of at least 1.5 m!
The mains voltage must not be interrupted (e.g. via a light switch).
If the leak protection system does not have a permanent power connection,
/ a possible leak may not be identified,
/ the water leak protection system cannot close in the event of a leak.
5.4

INSTALLATION DIMENSIONS

The leak protection system can be installed in horizontal or vertical pipes.
Installation dimension
A: Installation length with fittings
B: Device width
All dimensions in [mm] (see fig. 2)
Fig. 2: Installation dimensions
CLEAR STOP
195
203
43
