EN
Instructions
IMPORTANT:
• READ THESE INSTRUCTIONS CAREFULLY BEFORE USE AND KEEP THEM FOR FUTURE REFERENCE.
• YOUR CHILDREN'S SAFETY MAY BE AFFECTED IF YOU DO NOT FOLLOW THESE INSTRUCTIONS.
1 TO OPEN THE STROLLER
A Release storage clip.
B Open out the stroller.
C Using foot, push the brake pedal down fully to engage the primary locks.
WARNING: Ensure that all locking devices are engaged before use.
2 TO OPERATE BRAKES
Locate the brake lever at the back of the buggy frame.
A TO ENGAGE BRAKES: With foot, press down on the left side of the pedal.
B TO RELEASE BRAKES: With foot, press down on the right side of the pedal.
WARNING: Parking device shall be engaged during the loading and unloading
of children.
WARNING: Ensure parking device is engaged before leaving the buggy
unattended.
3 TO OPERATE FRONT WHEEL SWIVEL LOCKS
A TO LOCK SWIVELS: Align front wheels and press down on locking levers.
B TO UNLOCK SWIVELS: Raise locking levers.
4 SEAT BELT/SHOULDER HARNESS OPERATION
WARNING: The seat is not suitable for children under 3 months
WARNING: Avoid serious injury from falling or sliding out. Always use the crotch
strap in combination with the waist and shoulder straps.
TO FIT HARNESS:
A Pull shoulder straps over the childs shoulder then attach to the waist
clips by sliding strap loops onto the hooks.
B Insert both waist clips into the clasp, shoulder straps are secured once
the clips are fastened.
C Adjust strap lengths by sliding buckles. Belt and harness should be snug.
'D' rings are included for an additional harness, if desired.
TO RELEASE HARNESS:
D Press the button on both the front and back of the clasp simultaneously
to release.
5 TO ADJUST SEAT RECLINE
A TO RECLINE SEAT BACK: Lift both hand grips to release seat locks and
slide the seat back to desired position. Lower hand grips to engage locks
on both sides.
B TO RAISE SEAT BACK: From rear of stroller push seat back to original
upright or desired intermediate position.
6 TO OPERATE THE LEGREST
TO EXTEND THE LEGREST: Feel through seat corner openings. Locate sliders
and pull forward. Reverse this process to retract legrest.
All manuals and user guides at all-guides.com
7 TO FIT THE SHOPPING BAG
8 TO ATTACH THE HOOD
9 TO FIT THE RAIN APRON
10 REMOVING AND REFITTING THE SEAT COVER
11 TO REMOVE THE CARRY STRAP
12 TO FOLD THE STROLLER
CAUTION: Overloading may cause a hazardous unstable condition to exist.
Maximum load 4.4 lb (2 kg) evenly distributed.
The stroller may be folded with the bag still attached but all contents must be
removed. Failure to do this could damage stroller and contents of shopping bag.
A Place bag on the 'X' frame under seat with lowest edge of bag at front.
B Attach front straps to front legs just below seat.
C Attach rear straps to rear legs just above horizontal tie bar.
CAUTION: Overloading may cause a hazardous unstable condition to exist.
Maximum carrying capacity of hood pouch - 1.1lb (0.5kg.)
A Slide left hand and right hand pivot blocks DOWN over the retainers
located on the handle tubes.
B Place rear apron behind seat back.
C Extend hood and press down on side hinges to lock open.
A Place the apron over the hood front.
B Attach two eyelets (one each side) to the hood clips.
C Attach the two eyelets (one each side) to the front legs.
Remove hood from stroller if fitted.
A Twist shoulder strap end buckles and feed through holes.
B Feed waist and crotch straps through holes.
C Unclip seat cover retaining straps.
D Unfasten seat fabric from handle tubes and seat base.
E Slide fabric from seat back and base.
F Reverse this procedure to refit the seat cover and harnesses ensuring
seat back support tubes are inserted into fabric fold.
A Release the primary lock and secondary lock.
B Press clip release and remove clip from 'D' ring.
C Slide strap loops from handles.
D Using foot, push the brake pedal down fully to engage the primary lock.
Ensure the seat back is in its fullest upright position and the hood(if fitted) is
folded back
Remove contents of shopping bag.
It is recommended that the harness is fastened before folding the stroller.
A Using foot, lift up on brake pedal to release primary lock.
B Push down on secondary lock lever.
C Grip handles and push forward on stroller.
D Compress folded stroller and engage storage clip.
