Important information
SAFETY INFORMATION
This manual describes installation and service
procedures. The manual must be left with the customer.
DECLARATION OF CONFORMITY FOR THE
PRODUCT
Hereby, NIBE declares that the radio equipment type
E0003-A-001 is in compliance with Directive 2014/53/EU
and RoHS 2011/65/EU. The full text of the EU Declaration
of Conformity is available at nibe.eu
OPEN SOURCE CODE
This product contains software covered by an open
source code licence.
For more information as well as access to the source
code, visit opensource.nibe.eu
Please refer to the main product manual for full details of
how to mount and connect the device.

Technical data

CMO 40 Wifi module
Rated voltage (through main product)
Protection rating
Rated impulse withstand voltage
Degree of contamination
Energy source class 1 in accordance with the EN 62368-1 standard
Cable length for connection to main product
Wireless devices
IEEE 802.11 b/g/n: 2412 to 2472 MHz
IEEE 802.15.4: 2405 MHz to 2480 MHz
Dimensions and weight
Width
Height
Depth
Weight (without packaging and enclosed components)
Other data
Humidity measuring range, non-condensing
Ambient temperature
MARKING
The CE mark is mandatory for most products
that are sold in the EU, regardless of the
country of origin.
Class III control symbol
RECYCLING
Leave the disposal of the packaging to the
installer who installed the product, or to special
waste stations. When the product has reached
the end of its useful life, it must not be disposed
of with normal household waste. It must be
taken to a special waste collection centre or to a dealer
providing this type of service.
Failure by the user to dispose of the product correctly
will result in administrative penalties being imposed in
accordance with applicable legislation.
12DC 250mA
IPX0
kV 4
2
m <50
dbm 18
dbm 0
mm 85
mm 85
mm 36
g 80
%RH 0 – 90
°C 0 – 55
