TECHNICAL DATA

Power supply
Switching current
Protection type
Protection class
Switching time
permissible
temperature range
Power reserve
Accuracy
Standby consumption*
Mounting type
* The clock is always ready for operation to execute the set switching times and
additional functions�
230V AC / 50Hz
3A / 230 VAC inductive load
IP 20
II after the respective
installation
180 seconds
0° C to 50° C
approx. 5 hours
approx. +/- 1 seconds / day
0.5 watts
flush mount wall box,
Ø 60 mm, hole spacing, min.
25 mm depth
on-wall mountable with
corresponding housing
