EN
Specific safety instructions
• Check your powertool for damage before
starting your work, particularly the diamond
blade. All parts must be fitted properly and
must meet all requirements in order to
guarantee the tool's smooth operation. Any
safety guards or any lightly damaged parts
must be checked to see if they still function
properly before continuing the use of the tool.
Moving parts, and the diamond-blade guard in
particular, must be fitted properly and must not
jam. Do not use tools that cannot be switched
on or off with the switch.
• The diamond-blade guard must not be
jammed or removed.
• A jamming guard must be repaired
immediately.
• The riving knife must not be removed.
Electrical safety
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Always check that the power supply
corresponds to the voltage on the rating
plate.
connecting to the power supply
Check that the power supply and plug used in
accordance with tour tool. Have a look at the rating
plate on the tile cutter. Any changes should always
be carried out by a qualified electrician.
We strongly recommend the use of an
RCD (Residual Current Device) of not
more than 30 mA, at the plug socket
when using this appliance.
Warning! This machine must be earthed.
If not properly earthed this machine can cause an
electrical shock. Be sure that the power supply
outlet is earthed. If there is any doubt, have it
checked by a qualified electrician.
Warning! Avoid contact with the
terminals on the plug when installing
(removing) the plug to (from) the power
supply outlet. Contact will cause a severe
4
electrical shock.
replacing cables or plugs
Immediately throw away old cables or plugs when
they have been replaced by new ones. It is
dangerous to insert the plug of a loose cable in the
wall outlet.
using extension cables
Only use an approved extension cable suitable for
the power input of the machine. The minimum
conductor size is 1.5 mm
reel always unwind the reel completely.
PrcD
Portable residual current device
connection to water supply
1) For tools intended to be connected to a water
supply, instructions for the connection to the
water supply, the use of the water and the use
of attachments to comply with 14.5 in order to
avoid affection of the tool by water, the
inspection of hoses and other critical parts
which could deteriorate and the maximum
permitted pressure of the water supply.
2) For tools intended to be connected to a water
supply, the substance of the following
instructions, if applicable:
• For tools provided with a PRCD: Never use
the tool without the PRCD delivered with the
tool,
• For tools provided with an isolating
transformer: Never use the tool without the
transformer delivered with the tool or of the
type as specified in these instructions,
• Replacement of the plug or the supply cord
shall always be carried out by the
manufacturer of the tool or his service
organisation,
• Keep water clear off the electrical parts of the
tool and away from persons in the working
area.

3. Assembly

Assembly
Fig.1
• Mounting the riving knife.
• Unscrew the two (crosshead) screws (9) and
place the foot of the riving knife (10) under the
table.
• Place the small plate (2 holes with thread)
. When using a cable
2
