TilE cuTTEr
The numbers in the text refer to the diagrams
on page 2
For your own safety and that of others, we
recommend that you read this instruction
manual carefully before using this saw.
Keep this instruction manual and the
documentation provided with the saw for
future reference.
introduction
This tool is suitable for cutting various wall and
floor tiles with a maximum tile size of 500 x 500 x
35 mm. The diamond wheel can be replaced by
the customer. It is not permitted to use the tool for
any other materials.
contents
1. Machine information
2. Safety instructions
3. Assembly
4. Operation
5. Service & maintenance

1. Machine information

Technical specifications
Voltage
Frequency
Power consumption
IP Class
No load speed
Max. depth of cut 90º
Max. depth of cut 45º
Cutting angle
Ø Cutting blade
Table dimensions
Lpa (sound pressure level)
Lwa (sound power level)
Vibration
*S2= Maximum period of operation with a
capacity of 600 W
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in EN
61029; it may be used to compare one tool with
another and as a preliminary assessment of
exposure to vibration when using the tool for the
Ferm
230 V~
50 Hz
600W/S2=10 min*
IP20
2950/min
34 mm
18 mm
0 - 45°
Ø180 x Ø22.2 x 2.2 mm
360 x 330 mm
92+3 dB(A)
105+3 dB(A)
<2.5 m/s
2
applications mentioned
• using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level
• the times when the tool is switched off or when
it is running but not actually doing the job, may
signifi cantly reduce the exposure level
Protect yourself against the effects of
vibration by maintaining the tool and its
accessories, keeping your hands warm, and
organizing your work patterns.
contents of packing
1 Tile cutter
1 Water tray
1 Full-length adjustable fence
1 Set of instructions
1 Safety instructions
1 Guarantee card
Check the machine, loose parts and accessories
for transport damage.
2. Safety instructions
Explanation of the symbols
Denotes risk of personal injury, loss of life
or damage to the tool in case of non-
observance of the instructions in this
manual.
Indicates electrical shock hazard.
Immediately unplug the plug from the
mains electricity in the case that the cord
gets damaged and during maintenance.
Wear ear and eye protection.
Faulty and/or discarded electrical or
electronic apparatus have to be collected
at the appropriate recycling locations.
