SYSTEM PROBLEMS - MAINTENANCE - TECHNICAL DATA
SYSTEM PROBLEMS
Should a problem occur, the system signals the failure by flashing the red LED on the electronic circuit board. Refer to the
table below to get details on the type of error:
Key to the PSS circuit board error signals (see circuit board detail on page 10
NUMBER OF RED LED FLASHES
1
2
3
4
5
6
7
MAINTENANCE
The PSS needs no particular maintenance. To ensure optimum performance from the PSS once a year check the cables
and the electrical connections.

TECHNICAL DATA

MODEL
INPUT CHARACTERISTICS
Supply voltage (1)
Current absorption (2)
Maximum current absorption (3)
CONTACTOR
Tension contact max.
interruption capacity (4)
AMBIENT CHARACTERISTICS
Operating temperature
GENERAL
Dimensions (W x H x D)
Weight
EMC standard
(1) With supply voltage less than 8 Vdc the system can reset.
(2) Typical value.
(3) Typical value during close contact phase.
(4) 5 ms time constant.
®
QUICK RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
PSS PARALLEL SERIE SWITCH - REV000A
ERROR DESCRIPTION
T1 contact stuck
High battery voltage
Low battery voltage
F2 fuse open / T1 contactor not working
Low battery voltage/T2 contactor not working
Contact of T2 contactor stuck
F4 fuse open
PSS24
from 9 to 16 Vdc
13 mA
8A
48 Vdc
1500 A @ 48 Vdc
EN 60945 - FCC TITLE 47 PART 15 SUBPART B CLASSE B
from 18 to 32 Vdc
1500 A @ 96 Vdc
from -15 to +50 °C
307 mm x 257 x 124 mm
3,9 kg
GB
PSS48
13 mA
4A
96 Vdc
