exone go Handbuch Seite 26

Interface
One USB 3.0 (USB 3.1 Gen 1) Type-C Port*
*The maximum amount of current supplied
by USB Type-C ports is 500mA (USB 2.0)/
1500mA (USB 3.1).
One USB 3.0 (USB 3.1 Gen 1) Type-A Port
Two USB 2.0 Ports
One HDMI-Out Port
One External Monitor Port
One Microphone-In Jack
One 2-In-1 Audio Jack (Headphone and
Microphone)
One RJ-45 LAN Jack
One DC-In Jack
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth
Module
(Factory Option) Slot 2 for 4G Module
22
Communication
Built-In 10/100/1000Mb Base-TX Ethernet
LAN
1.0M HD Webcam
(Factory Option) 4G M.2 Module
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wire-
less-AC 9260 Wireless LAN (802.11ac) +
Bluetooth
(Factory Option) Intel® Dual Band Wire-
less-AC 9560 Wireless LAN (802.11ac) +
Bluetooth
(Factory Option) Intel® Dual Band Wire-
less-AC 9462 Wireless LAN (802.11ac) +
Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 6
AX200 Wireless LAN (802.11ax) + Blue-
tooth
(Factory Option) Realtek Dual Band Wi-Fi
5 RTL8821CE Wireless LAN (802.11ac) +
Bluetooth
Power
Removable 4 Cell Smart Lithium-Ion Bat-
tery Pack, 31WH
(Factory Option) Removable 4 Cell Smart
Lithium-Ion Battery Pack, 41WH
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 2.1A (40W)
Environmental Spec
Temperature
° °
Operating: 5 C - 35 C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions & Weight
361mm (w) * 256mm (d) * 24.1mm (h)
(Height Excluding Battery Area)
2.2kg (Barebone with ODD and 31WH Bat-
tery)
