DEPTH GAUGE
1
Loosen the auxiliary handle
3
and slide
the depth gauge into the auxiliary han-
dle 3.
Caution! Make sure the tool is
switched off and unplugged.
DUST COVER
1
Attach the dust cover to the chisel or
drill.
Caution! Make sure the tool is
switched off and unplugged.
HAMMER FUNCTION
1
Press the locking button and set the
top hammer-drill/ hammer switch
hammer .
Caution! Only set operation modes
while the aplliance is switched off.
HAMMER-DRILL FUNCTION
1
Press the locking button and set the
top hammer-drill/ hammer switch
hammer-drill
Caution! Only set operation modes
while the aplliance is switched off.
DRILL FUNCTION
1
Press the locking button and set the
top hammer-drill/ hammer switch
hammer-drill
.
Caution! Only set operation modes
while the aplliance is switched off.
108
EN
2
Set the desired clearance of the depth
gauge and tighten the auxiliary handle
screw securely.
2
Use the dust cover to prevent dust from
falling on you or the tool when perform-
ing overhead drilling-operations.
2
Set the rear hammer-drill/ drill switch
7
to
to hammer-drill
.
2
Set the rear hammer-drill/ drill switch
7
to
to hammer-drill .
2
Set the rear hammer-drill/ drill switch
7
to
6
to drill .
1
1. 1.
1
2. 2.
6
1
1. 1.
2. 2.
6
1
2. 2.
1
2
2. 2.
2. 2.
2
2
2
1. 1.
2
1.
1.
1. 1.
EN
109
