LaserLiner AC-tiveM aster Bedienungsanleitung Seite 12

5 Determining the direction of the rotating eld
Clockw ise rotating eld
If the R LED (8) lights up, it
means that w hat you think is
phase L1 really is phase L1 and
that w hat you think is phase
L2 really is phase L2.
!
When you crosscheck this by sw itching round the test
prods, the opposite symbol should light up instead.
6 Battery lamp
To sw itch on the battery lamp, press and hold dow n button
10. The light sw itches itself off automatically as soon as the
button is released.
7
Calibration
The voltage tester needs to be calibrated and tested on a regular
basis to ensure it produces accurate measurement results. We
recommend carrying out calibration once a year.
EU directives and disposal
This device complies w ith all necessary standards
for the free movement of goods w ithin the EU.
This product is an electric device and must be
collected separately for disposal according to
the European Directive on w aste electrical and
electronic equipment.
Further safety and supplementary notices at:
w w w.laserliner.com/info
12
GB
Anticlockw ise rotating eld
If the L LED (7) lights up, it
means that w hat you think
is phase L1 is actually phase
L2 and that w hat you think is
phase L2 is actually phase L1.
