DESCRIPTION AND SPECIFICATIONS
Integrated Amplifier: 125watt @ 8Ω per channel class AB
Mosfet
Streamer: Tidal, Qobuz, MQA, vTuner, Spotify, Deezer
Airplay and Roon Ready
App GN Control (available on iOS & Android)
Ethernet LAN and Wi-Fi (PCM24/192 and DSD64)
UPnP and DLNA supported
Phono Stage MM/MC
DAC IS-1000: BurrBrown PCM1796
DAC IS-1000 LINE: BurrBrown PCM1796
DAC IS-1000 DELUXE: BurrBrown PCM1792A
THD (Total Harmonic Distortion): 0,005% @ 5W
0,1% @ 0,1 to 50W (20Hz - 20kHz)
Damping Factor: >100
Output impedance: 50Ω
Ration Signal/Noise: >100dB Line and Digital Inputs
>80dB Phono (MM)
Booster: 3 adjustable levels (by-passable/off)
ANALOG OUTPUTS
1 RCA variable
1 RCA fixed
ANALOG INPUTS IS-1000/ IS-1000 DELUXE
1 XLR balanced
1 RCA Line / Phono MM/MC
1 RCA Line / AV-In
ANALOG INPUTS IS-1000 LINE
1 XLR balanced
1 RCA Line
1 RCA Line / AV-In
DIGITAL INPUTS
3 Optical Tos-Link PCM up to 24bit/192kHz
1 RCA Coax PCM up to 24bit/192kHz
1 USB-A port DSD64 and PCM up to 24bit/192kHz,
formatted in FAT32/NTFS (32Gb max for pen drives)
5
POWER
100-120V or 220-240V, 50/60Hz
Power consumption: 30W - 400W max
Standby consumption: < 0,5W
Fuse 220/240V 3,15A F/T
Fuse 100/120V 6,3A F/T
SUPPORTED STREAMING SERVICES:
TIDAL & MQA via Tidal
Qobuz
Spotify & Spotify Connect
Deezer
V-Tuner
SUPPORTED MEDIA SERVERS:
Minim
Bubble UPnP
All certified UPnP media servers
SUPPORTED AUDIO FORMAT:
AIFF (aif, aiff, aifc)
WAV (wav) packed/unpacked
FLAC
WmA Windows media Audio 9
WAX Windows media audio metafiles
ASX Advanced Stream Redirector (asx)
MPEG-4 (aac, m4a , Apple lossless)
MP3
DSD64 [.dsf] files converted to high-resolution PCM over
UPnP protocol
DIMENSIONS AND WEIGHT
Dimensions: 430 W x 135 H x 375 D mm
Weight: Kg. 18 net - Kg. 23 boxed
APP
GN Control
