Gold Note ES-78 Bedienungsanleitung

THANK YOU FOR PURCHASING THE
ES-78 STEREO CARTRIDGE.
PACKAGE CONTENT
| Cartridge body
| Set of head-shell fixing 2,5mm screws (non-
magnetic)
| User Manual
ES-78
Type Cantilever
MM Phono Cartridge Aluminium
Output level Diamond
4mV Conical
Frequency response Diamond size
15 - 25000Hz 7.5×15.5µm
Impedance Coil Wire
1000Ω Copper
Inductance Magnet
500mH Alnico
Compliance Hole-diamond distance
10×10-6cm/dyne 9mm
Channel separation Total weight
>20dB 6g
Channel balance Body
<2dB POM
BEFORE USING
1 The stylus is very delicate and applying excessive
force to the stylus, such as finger pressure, can
result in damages. Handle the cartridge with the
utmost care.
2 A powerful magnet is used in the cartridge.
Operating steel/magnetic tools or similar items
near the cartridge will exert a force on the
magnet and may result in damages to the stylus
and the cartridge.
ES-78
The ES-78 phono cartridge has been designed to offer
great audio performances and ease of use. The design
of the cartridge stems from our philosophy, combining
technology and performance.
The body is made of black POM with high-dampening
qualities and the ultra-rigid Aluminium cantilever
features a conical diamond tip exclusively developed for
our cartridge. To let you enjoy even the finest details,
the cantilever is directly installed into the POM body
resulting in enhanced structural rigidity and superior
tracking ability.
Thanks to its output level, the ES-78 goes particularly
well with high-quality MM phono stages and thanks to
the extremely light weight, only 6 grams, it is an ideal
companion for our Valore 425 turntable.
The ES-78 delivers an impressive sound quality making
it the perfect cartridge to start the exploration of the
world of analogue music.
