9. Faults and how to remedy them

Fault
Sound but no
picture is
transmitted
No image from the
camera is shown,
just the list of
available cameras
No alarm message
is sent to the
smartphone
Image sensor
Video illumination
Compression
Resolution
White balance
Audio
Temperature sensor
Operating temperature
Storage temperature
Air humidity
Power input
Mains connection
RF frequency range
Wi-Fi standard
RF initial output
RF sensitivity
Range in open
Antenna
Internet bandwidth
Cause
The bandwidth (data transmission
rate) of the connection is
inadequate
The UID has not been transmitted
correctly
Messages have been switched off Switch on messages (see "6.1.2 Inputting

10. Technical data

CMOS
8 infra-red LEDs
Min. 3 LUX light intensity
Baby's face clearly visible within 2 metres
H.264
640X480 VGA or QVGA
Automatic
Two-way talk function via analogue microphone and loudspeaker at
0.5 W, 16 kHz
NTC type, 10 kΩ at 25 °C; deviation +/- 2 °C
0° C to 40° C ambient temperature
-20 ° C to 70 ° C ambient temperature
40 to 90% rH (no condensation)
External DC 5.8 V - 1000 mA
EU specifications 100 ~ 240 V 50/60 Hz
Wireless connection
2412 MHz - 2462 MHz (channel 1~11)
802.11b/g/n
11b: 21 +/- 1 dBm/11 Mbps;
11g: 18 +/- 1 dBm/54 Mbps;
11n: 17 +/-1 dBm/HT20 - 11n: 17 +/- 1 dBm/HT40
11b: -88 dBm/11 Mbps;
11g: -74 dBm/54 Mbps;
11n: -71 dBm/MSC7/HT20 - 11n: -68 dBm/MSC7/HT40
80 m
Dipole
QVGA: min. required 1 Mbps, recommended 2 Mbps
VGA: min. required 2 Mbps, recommended 4 Mbps
Set camera settings to the lower values (see
"7.2.3 Camera settings" on page 33).
Enter camera data using QR code or by
hand (see "6.1.2 Inputting camera data
manually" on page 28).
camera data manually" on page 28).
Camera
35
Remedy
