Figure 1: Pressio® ICP monitoring kit, parenchymal tunneling (Model PSO-PT).
ø1.2 mm
40 mm
ø2.7 mm
Drill bit with adjustable stop and Allen wrench
Figure 2: Pressio® ICP & ICT monitoring kit, parenchymal tunneling (Model PSO-PTT)
ø1.2 mm
40 mm
ø2.7 mm
Drill bit with adjustable stop and Allen wrench
1000 mm
ø0.7 mm
Pressio® intracranial pressure
measurement catheter
Fixation tab
1000 mm
ø0.7 mm
Pressio® intracranial pressure and
temperature measurement catheter
Fixation tab
3/78
Tunneling needle
Tunneling needle
