the same frequency band as your indoor and/or outdoor sensors and
experience intermittent communication between sensor and console, try
turning off these other devices for troubleshooting purposes. You may need to
relocate the transmitters or receivers to avoid the interference and establish
reliable communication. The frequency used is 868.
1. Line of Sight Rating. This device is rated at 300 feet line of sight (no
interference, barriers or walls) but typically you will get 100 feet
maximum under most real-world installations, which include passing
through barriers or walls.
2. Metal Barriers. Radio frequency will not pass through metal barriers
such as aluminum siding. If you have metal siding, align the remote
and console through a window to get a clear line of sight.
The following is a table of reception loss vs. the transmission medium.
Each "wall" or obstruction decreases the transmission range by the factor
shown below.
Medium
Glass (untreated)
Plastics
Wood
Brick
Concrete
Metal
4.4
Display console
The front and back of the display console is shown in Figure13.
Figure 13: Display console front and back
Reference Figure 14.
(1) Unfold the desk stand and place the console 5 to 10 feet away from the
Table 5: RF Signal Strength reduction
RF Signal Strength Reduction
5-15%
10-15%
10-40%
10-40%
40-80%
90-100%
58
