EN: User manual seating system V3000

1 General safety instructions

Make sure all seats are securely locked before you start your journey.
There is a risk of injury when moving or transforming the seats. At all times, make sure that there are
no limbs in the range of movement of the seats or moving seat parts.
Do not leave children unattended to avoid injuries by moving parts.
Do not transport heavy objects on the seats, nor do you place sharp-edged, hot or wet objects on
them.
2 Seat bench V3000
Depending on the vehicle and the seating system, up to six driving positions and one transport position
for the seat bench as well as two positions for a single seat are possible. Make sure that all seats are
securely locked in one of these positions before starting your journey.
Abb. 2-1: Locking the bench [G0002180-001_00]
This is the only way to avoid unwanted movement of the seats as well as the associated risk of acci-
dents and injuries.
The bench positions are defined in the rails by the holes with a diameter of 20.5 mm for the release pin. The position
of the single seat through holes with a diameter of 19.2 mm.
Driving position Bench
Abb. 2-2: As an example, a rail of the VW T6.1 LR with glued mounting [T0001541-001_01]
W0003107-001_00
Position single seat
Removal opening
24.05.2022 10:32
Transport position
