Disposal of old equipment
When to be definitively put out of operation, take the product to a local recycling plant for a disposal
which is not harmful to the environment. Devices marked with this symbol must not be disposed of as
household waste. Contact your retailer or local authorities for more information. Remove any inserted
batteries and dispose of them separately from the product.
Power supply:
Power consumption:
Power connection:
IP classification:
DMX channels:
Carrier frequency:
Modulation:
Coverage:
Antenna:
DMX connector:
Dimensions with antenna (L x W x H): 173 x 156 x 92 mm
Weight:
Specifications are subject to change without notice due to product improvements.
PROTECTING THE ENVIRONMENT
TECHNICAL SPECIFICATIONS
QuickDMX transceiver
230 V AC, 50 Hz
1 W
IP T-Con (cable provided)
IP65
512 (1 universe)
2.4 GHz ISM band, 78 channels
GFSK
up to 600 m (line-of-sight)
5 dBi
3-pin XLR IP (pin 1: ground, pin 2: signal -, pin 3: signal +)
0.9 kg
173mm
15 • EN
99mm
156mm
