Routine Maintenance; Main Brush - Xiaomi Roborock S7 MaxV Plus Bedienungsanleitung

App Features
Cleaning Map
• Multi-map management
• Real-time vacuum and mop route
• Carpet display
• Map zoning
• Map editing
Custom Cleaning Modes
• Scheduled
• Selective Room
• Zone
• No-Go Zones, No-Mop Zones, and
Invisible Wall
• Custom
• Carpet Boost
Cleaning Mode Switch
• Suction Power Levels
• Mop Intensity Levels
Robot Information
• Cleaning History
• Battery Level
• Care & Maintenance
More Features
• Firmware Update
• Video Call
Note: Only available in the Roborock app.
• Volume Adjustment
• Language Selection
• Do Not Disturb Mode
• Voice Assistant Support
Note: Functions and details of the app may vary slightly due
to the continuous app development and updates.
Routine
C
Maintenance

Main Brush

C1
* Clean every 2 weeks and replace every 6-12 months.
C1-1—
Main Brush Cover
C1-2—Latches
C1-3—
Main Brush
C1-4—
Main Brush Caps
C1-5—
Main Brush Bearing
C1-6— Turn over the robot and press the
latches to remove the main brush cover.
C1-7— Pull out the main brush and remove
the main brush bearing.
C1-8— Rotate the main brush caps in the
indicated unlock direction to remove
the caps.
C1-9— After removing the tangled hair or
dirt at both ends of the main brush,
reinstall it, press on the main brush
cover to lock it in place.
Notes:
• Main brush should be wiped down with wet cloth and left
to dry away from direct sunlight.
• Do not use corrosive cleaning fluids or disinfectants to
clean the main brush.
Side Brush
C2
* Clean monthly and replace every 3-6 months.
1. Unscrew the side brush screw.
2. Remove and clean the side brush.
Reinstall the brush and tighten the screw.
012
Omni-Directional Wheel
C3
* Clean as required.
C3-1— Use a tool, such as a small
screwdriver, to pry out the axle and
take out the wheel.
Note: The omni-directional wheel bracket cannot be removed.
C3-2— Rinse the wheel and the axle with
water to remove any hair and dirt.
Dry and reattach the wheel, pressing
it firmly in place.
Main Wheels
C4
* Clean monthly.
Clean the main wheels with a soft, dry cloth.
Dustbin
C5
* Clean as required.
C5-1— Open the top cover of the robot and
take out the dustbin.
C5-2— Open the dustbin cover and remove
the filter, then empty the dustbin.
C5-3—
Fill the dustbin with clean water and
close the cover. Gently shake the
dustbin, and then pour out the dirty
water.
Note: To prevent blockage, only use clean water without any
cleaning liquid.
C5-4— Leave the dustbin and the washable
filter to dry.
