Product Overview

A
Robot (Top View)
A1
Power/Clean
• Press and hold to turn the robot
on or off
• Press to start cleaning
Power Indicator
• White: Battery level ≥ 20%
• Red: Battery level < 20%
• Pulsing: Charging or starting up
• Flashing red: Error
Spot Clean/Child Lock
• Press to Spot clean
• Press and hold for 3 seconds to
turn on/off the child lock
Dock
• Press to return to dock/start
emptying
Note: Press any button to stop the robot during cleaning
or docking.
A1-1—Vertical Bumper
A1-2—Microphone
• For use with Video Calls
Note: Only available in the Roborock app.
A1-3—Status Indicator Light
• White: Vacuuming
• Blue: Vacuuming and Mopping
• Orange: Alert
• Green: Docking/Recharging
A1-4—Wall Sensor
A1-5—Bumper
A1-6—Charging Contacts
A1-7—ReactiveAI Obstacle Recognition
A1-8—LED Fill Light
Robot (Bottom View)
A2
A2-1—Cliff Sensors
A2-2—Carpet Sensor
A2-3—Omni-Directional Wheel
A2-4—Charging Contacts
A2-5—Side Brush
A2-6—Main Wheel
A2-7—Main Brush
A2-8—Main Brush Cover Latches
Robot (Upper Cover Open)
A3
A3-1—WiFi Indicator light
• Off: WiFi disabled
• Flashing slowly: Waiting for
connection
• Flashing quickly: Connecting
• Steady: WiFi connected
A3-2—Reset Button
A3-3—Air Inlet
A3-4—LiDAR Sensor
A3-5—Mop Wash Sensor
A3-6—Water Tank Latch
A3-7—Positioning Button
A3-8—Water Tank
A3-9—VibraRise Module
A3-10—Air Outlet
007
Dustbin
A4
A4-1—Filter Cover
A4-2—Dustbin Latch
A4-3—Cover Latch
A4-4—Air Inlet
A4-5—Washable Filter
Electric Water Tank
A5
A5-1—Stopper
A5-2—Water Filter
A5-3—Water Tank Latch
A5-4—Self-Filling Port
VibraRise Mop Bracket
A6
A6-1—Vibration Module
A6-2—Mop Cloth Attachment Slot
A6-3—Mop Bracket Latches
VibraRise Mop Cloth
A7
A7-1—Hook and loop pads
Power Cable
A8
Dust Bag Holder
A9
Disposable Dust Bag
A10
Screwdriver
A11
