Filter Cleaning

C13
* Clean as required.
Notes:
• Do not wash the filter in a dishwasher or washing machine,
or dry using a cylinder dryer, oven, microwave, hot air or
fire.
• Do not touch the surface of the filter with your hands,
brush, or hard objects to avoid potential damage.
• Rinse the filter element with clean water. Do not remove it
from the front filter.
C13-1— Rotate the filter cover counter-
clockwise to remove it.
C13-2— Remove the front filter and/or the
rear HEPA filter as needed.
C13-3— Rinse with cold water until clean.
C13-4— Shake off any remaining water and
leave the filter to dry for 24 hours
or until completely dry.
C13-5— Reinstall the dry filter and close the
cover.
Air Duct
C14
* Clean as required.
C14-1— Clean the dust inlet with a cotton
swab if it gets blocked.
C14-2— Unscrew the screws (7) and remove
the cover.
C14-3— Wipe the air duct and cover with a
dry cloth.
C14-4— Re-install the cover and screw it
back in place.
Dust Bag Replacement
C15
* Clean as required.
Notes:
• Replace the disposable dust bag when full.
• The disposable dust bag uses a one-time seal design to
effectively prevent dust from spreading outward during
replacement. If you do not want to discard the dust bag,
do not pull out the seal. If the seal is pulled out, it cannot
be restored to the original state, which will affect the use
of the dust bag.
C15-1— Remove the dustbin vertically as
shown.
C15-2— Press the Dustbin Opener to open
the bottom lid of the dustbin.
C15-3— Pull out the bag as shown and
discard the dust bag.
Note: The dust bag handle seals the bag on removal to
prevent leakage.
C15-4— Replace the dust bag with a new
one. Make sure it is properly
installed.
C15-5— Close the bottom lid of the dustbin
and place it back in the dock.
Clean the dock location
C16
beacon, charging
contacts, and electrode
brushes with a dry cloth.
* Clean as required.
014

Basic Parameters

Robot
Model S270RR
14.4V/5200mAh
Battery
lithium-ion battery
Weight Approx. 4.7kg
Rated Input 20V 1.2A
Charging Time < 6 hours
Note: The serial number is on a sticker on the underside of
the robot.
Auto-Empty Dock
Name Auto-Empty Dock
Model AED01HRR, AED02HRR
Rated Input Voltage 220-240V~
Rated Frequency 50-60Hz
Rated Power
28W
(Charge)
Rated Power
1000W
(Dust Collection)
Rated Output 20V 1.2A
14.4V/5200mAh
Charging Battery
lithium-ion battery
