junger MIX4 Bedienungsanleitung Seite 68

connector : Analog BUS 1-4
female 25-pin Sub-D
1 CH-8 (R) +
2 GND
3 CH-7 (L) -
4 CH-6 (R) +
5 GND
6 CH-5 (L) -
7 CH-4 (R) +
8 GND
9 CH-3 (L) -
10 CH-2 (R) +
11 GND
12 CH-1 (L) -
13 NC
14 CH-8 (R) -
15 CH-7 (L) +
16 GND
17 CH-6 (R) -
18 CH-5 (L) +
19 GND
20 CH-4 (R) -
21 CH-3 (L) +
22 GND
23 CH-2 (R) -
24 CH-1 (L) +
25 GND
connector : DIGITAL BUS 1-4
female 15-pin Sub-D
1 BUS+4
2 GND
3 BUS+3
4 GND
5 GND
6 BUS+2
7 GND
8 BUS+1
9 BUS-4
10 GND
11 BUS-3
12 GND
13 BUS-2
14 GND
15 BUS-1
MIX4 Steckverbinder
connector : IF AES I/O
female 25-pin Sub-D
1 BUS+4
2 GND
3 BUS-3
4 BUS+2
5 GND
6 BUS-1
7 IN-4+
8 GND
9 IN-3-
10 IN-2+
11 GND
12 IN-1-
13 NC
14 BUS-4
15 BUS+3
16 GND
17 BUS-2
18 BUS+1
19 GND
20 IN-4-
21 IN-3+
22 GND
23 IN-2-
24 IN-1+
25 GND
connector : Phones/Speaker
female 15-pin Sub-D
1 PH-2L
2 PH-2R
3 PH-1L
4 PH-1R
5 MON-L+
6 MON-L-
7 MON-R+
8 MON-R-
9 GND
10 GND
11 GND
12 GND
13 GND
14 GND
15 GND
Seite 65
Jünger Audio-Studiotechnik GmbH
connector : IF Analog IN
female 25-pin Sub-D
1 CH8+
2 GND
3 CH7-
4 CH6+
5 GND
6 CH5-
7 CH4+
8 GND
9 CH3-
10 CH2+
11 GND
12 CH1-
13 NC
14 CH8-
15 CH7+
16 GND
17 CH6-
18 CH5+
19 GND
20 CH4-
21 CH3+
22 GND
23 CH2-
24 CH1+
25 GND
connector : DIGITAL IN 1-4
female 15-pin Sub-D
1 DIG-IN4+
10 GND
11 DIG-IN3-
12 GND
13 DIG-IN2-
14 GND
15 DIG-IN1-
2 GND
3 DIG-IN3+
4 GND
5 GND
6 DIG-IN2+
7 GND
8 DIG-IN1+
9 DIG-IN4-
