Jünger Audio-Studiotechnik GmbH
RS232
connector :
female 9 pin Sub-D
1 RX+ RS422
2 TXD RS232
3 RXD RS232
4 NC
5 GND
6 RX- RS422
7 NC
8 TX- RS422
9 TX+ RS422
connector : Remote
RJ45
1 CAN-H
2 CAN-L
3 GND
4 GND
5 GND
6 +5V
7 +5V
8 +5V
connector : Ethernet
RJ45
1 Tx (+)
2 Tx (-)
3 Rx (+)
4
5
6 Rx (-)
7
8
MIX4 Steckverbinder
connector : GPI / TALLY
female 26 pin Sub-D
1 TALLY_1a
2 TALLY_2a
3 TALLY_3a
4 TALLY_4a
5 TALLY_5a
6 TALLY_6a
7 TALLY_7a
8 TALLY_8a
9 GND
10 TALLY_1b
11 TALLY_2b
12 TALLY_3b
13 TALLY_4b
14 TALLY_5b_6b
15 TALLY_7b_8b
16 GPI_1 (+)
17 GPI_1 (-)
18 +5V (110Ohm)
19 GPI_2 (+)
20 GPI_2 (-)
21 GPI_3_4 (+)
22 GPI_3 (-)
23 GPI_4 (-)
24 GPI_5_6 (+)
25 GPI_5 (-)
26 GPI_6 (-)
DCpower (opt.)
connector :
male 4 pin XLR
1 GND
2 N.C.
3 N.C.
4 +9V to +36V
Seite 64
connector : IF 2CH-MIC
female 25 pin Sub-D
1 MIC3 +
2 MIC3 GND
3
4
5
6
7
8
9
10
11
12 MIC4 -
13
14 MIC3 -
15
16
17
18
19
20
21
22
23
24 MIC4 +
25 MIC4 GND
connector : AUX OUT
female 9-pin Sub-D
1 AUX2-L+
2 GND
3 AUX2-R+
4 GND
5 AUX1-AES+
6 AUX2-L-
7 GND
8 AUX2-R-
9 AUX1-AES-
