Bake-out temperature
Voltage supply
Power consumption
Output signal
Serial interface
Switchpoints
Electrical connection
Vacuum connection
Protection class
Weight
max. 160 C at the flange (voltage supply
switched-off)
20 - 30 VDC
max. 3 W,
0.8 W for relays and LCD
0 - 10 VDC, min. 10 k ,
measuring range 1.82 - 8.6 VDC, logarithmic
RS485: 9.6 ... 115 kBd, 8 databit, 1 stopbit, no
parity
2x relay, potential free
50 VAC / 2 A or 30 VDC / 2 A, max. 60 VA
Sub-D, 15-pole, male, lockable
VSM77: small flange DN25 ISO KF
VSM78: small flange DN40 ISO KF
VSM79: conflat flange DN40 CF
IP 40 (IP 54)
555 g (VSM77)
