Spezifikationen
Endung ".0" und spezifizieren nur einen Wert. Bei SNMP Tabellen wird das "x" durch
einen Index (1 oder größer) ersetzt, um einen Wert aus der Tabelle zu adressieren.
Name
epc1105TrapCtrl
epc1105TrapIPIndex
epc1105TrapAddr
epc1105portNumber
epc1105PortIndex
epc1105PortName
epc1105PortState
epc1105PortSw itchCount
epc1105PortStartupMode
epc1105PortStartupDelay
epc1105PortRepow erTime
epc1105PortResetDuration
epc1105ActivePow erChan
epc1105Pow erIndex
epc1105ChanStatus
epc1105AbsEnergyActive
epc1105Pow erActive
epc1105Current
epc1105Voltage
epc1105Frequency
epc1105Pow erFactor
epc1105Pangle
epc1105Pow erApparent
epc1105Pow erReactive
epc1105AbsEnergyReactive
epc1105AbsEnergyActiveResetta
ble
epc1105AbsEnergyReactiveReset
Expert Power Control 1104 / 1105
OID
Description
.69.1.1.1.1.0
0 = off 1 = Ver. 1 2 = Ver. 2c 3 = Ver. 3
.69.1.1.1.2.1.1.x
A unique value, greater than zero, for each receiver slot.
.69.1.1.1.2.1.2.x
DNS name or IP address specifying one Trap receiver slot. A port can
optionally be specified: 'name:port' An empty string disables this slot.
.69.1.3.1.1.0
The number of Relay Ports
.69.1.3.1.2.1.1.x
A unique value, greater than zero, for each Relay Port.
.69.1.3.1.2.1.2.x
A textual string containing name of a Relay Port.
.69.1.3.1.2.1.3.x
current state a Relay Port
.69.1.3.1.2.1.4.x
The total number of sw itch actions ocurred on a Relay Port. Does not
count sw itch commands w hich w ill not sw itch the ralay state, so just
real relay sw itches are displayed here.
.69.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.69.1.3.1.2.1.6.x
Delay in sec for startup action
.69.1.3.1.2.1.7.x
Delay in sec for repow er port after sw itching off
.69.1.3.1.2.1.8.x
Delay in sec for turning Port on again after Reset action
.69.1.5.1.1.0
Number of suppported Pow er Channels.
.69.1.5.1.2.1.1.x
Index of Pow er Channel entries
.69.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.69.1.5.1.2.1.3.x
Absolute Active Energy counter.
.69.1.5.1.2.1.4.x
Active Pow er
.69.1.5.1.2.1.5.x
Actual Curent on Pow er Channel.
.69.1.5.1.2.1.6.x
Actual Voltage on Pow er Channel
.69.1.5.1.2.1.7.x
Frequency of Pow er Channel
.69.1.5.1.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.69.1.5.1.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.69.1.5.1.2.1.10.x
L Line Mean Apparent Pow er
.69.1.5.1.2.1.11.x
L Line Mean Reactive Pow er
.69.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.69.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.r.
.69.1.5.1.2.1.14.x
Type Acc.
Integer32 RW
Integer32 RO
OCTETS RW
Integer32 RO
Integer32 RO
OCTETS RW
INTEGER RW
Integer32 RO
INTEGER RW
Integer32 RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Unsigned32 RO
Integer32 RO
Unsigned32 RO
Unsigned32 RO
Unsigned32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Unsigned32 RO
Unsigned32 RW
Unsigned32 RO
