Install the hardware

The network camera can be mounted with the cables routed through or along the wall or ceiling.
!
IMPORTANT! - To use the network camera outdoors, it must be installed in an approved
outdoor housing. Please see www.axis.com for more information on outdoor products.

Prepare for installation

Read all the instructions before preparing to install the network camera since several installation
preparation steps require removing the dome ring and the dome cover and would benefit from
being completed together.
• The network camera is supplied with a clear transparent cover and a smoked transparent
cover. If required, follow the instructions
below to replace the dome cover.
• A standard or high capacity SD card (not included) is required to store images locally in the
network camera. Follow the instructions
dome cover and install an SD card.
Replace the clear/smoked dome cover (optional)
1. Loosen the 4 dome ring screws and remove the dome ring and the dome cover, see illustration
on page 6.
2. Remove the 4 dome bracket screws and remove the dome bracket and the dome cover from the
dome ring.
3. Attach the dome bracket and the dome cover to the dome ring and tighten the 4 screws.
4. If installing an SD card, refer to the instructions
5. Put the dome ring with the dome cover back in the original position and tighten the screws.
Note:
Be careful not to scratch or damage the dome cover. If possible, keep the protective plastic
on the dome cover until the installation is complete.

Install an SD card (optional)

1. Loosen the 4 dome ring screws and remove the dome ring and the dome cover, see illustration
on page 6.
2. Insert an SD card (not included) into the SDHC (Secure Digital High Capacity) card slot.
3. Put the dome ring with the dome cover back in the original position and tighten the screws.
Notes:
The SD card is automatically mounted when inserted into the SDHC card slot. However,
before removing the SD card it should be unmounted through the camera's web pages. Go
to Setup > System Options > Storage > SD Card and click Unmount. For more informa-
tion, please see the User Manual available from the AXIS Network Video Product CD sup-
plied with this product or from the website at www.axis.com
AXIS Q6032/Q6034/Q6035 Installation Guide
