AXIS Q6032/Q6034/Q6035 Installation Guide
8. Secure the camera using the supplied safety wire.
Ceiling bracket
Ceiling tile
9. Slide the unit holders on the network camera into the slots on the mounting plate and rotate
the camera unit.
10. Install the High PoE Midspan 1-Port, see
13.
11. Check that the indicator LEDs on the midspan indicate the correct conditions. See the table on
page 24 for further details.
12. Install the ceiling tile, with the camera mounted, into the ceiling.
13. Place the trim ring over the ceiling bracket and tighten the screws.
Safety wire
Install AXIS T8123 High PoE Midspan 1-port,
Trim ring
Trim ring screws
Page 11
Hook for
safety wire
on page
