gins to rotate slowly; with increased pres-
sure, the speed increases.
Always match the speed setting to the ma-
terial concerned and the diameter of the
drill bit.
6.5 Rotational direction
switching
Operate the rotational direction switch [1-7]
only when the machine is at a standstill!
Take hold of the rotational direction switch
[1-7] on both sides.
Clockwise rotation:
For drilling and fi xing screws.
Anticlockwise rotation:
For loosening and removing screws
and nuts.
Important: Press the rotational direction
switch [1-7] up to the stop on the housing,
i. e. until it snaps in audibly. If the rotational
direction switch [1-7] is set between the
positions ◄ and ►, the machine cannot be
switched on.
6.6 Selecting the modes
of operation
The operational mode switch [1-4] can be
used to select the required settings.
The switchover can be performed best at
standstill.
After the On/Off switch [1-5] has been actu-
ated and the machine has started, the gear-
box switches to the preselected setting.
a) Impact drilling
CAUTION
Wear protective glasses and hearing
protection.
► Left rotation when impact drilling damag-
es the drill. Switch off the impact mecha-
nism for diamond crown drilling or for
mixing work.
► When impact drilling, only use drills with
tungsten carbide inserts and SDS-plus
shafts.
WARNING
Do not use chucks for impact drilling
– you could damage them!
16
Drilling in tiles
Start drilling slowly on the tile. Only after the
tile is drilled through, switch to impact drill-
ing. This prevents the tile from cracking.
b) Drilling / Stirring / Screwing
Drilling with diamond drill bits
Switch the hammer action off when drilling
with a diamond drill bit.
Set the operation mode switch [1-4] to
drilling.
Screwing
The screw adapter [2-2] (accessory) can
hold screw bits.
Commercially available bits with a hexago-
nal dimension of 6.3 mm or 1/4" (DIN 3126,
Form C) can be used. The screw-bits are
held in the adapter with a spring ring.
Therefore, use only bits with a notch.
Set the operation mode switch [1-4] to
drilling.
7 Inserting / Removing
Tools
► Drilling instruments are clamped with the
SDS-plus system without using bracket
wrenches.

7.1 Inserting tools

Before any work on the machine itself, pull
the mains plug!
Clean and lightly grease the tool shaft.
Pull back the unlocking sleeve [2-1]. Insert
the tool while turning into the tool holder
[2-3] until it latches. Release the unlock-
ing collar. Check whether the tool is fi rmly
seated.
Take care that the dust protection cap is
not damaged.
WARNING
Replace damaged dust protection
caps!

7.2 Removing tools

Slide the unlocking sleeve [2-1] to the rear
and pull out the tool.
