8

Accessories

WARNING
Before carrying out any work on the
machine, pull the mains plug.
All common drill chucks with 1/2" × 20 UNF
internal threads (13 mm max. chuck open-
ing) can be used. The drill chuck is mounted
on the screw adapter [2-2] (accessories)
for screw-bits.

8.1 Screw adapter assembly

Retract the unlocking sleeve [2-1].
Insert the screw adapter [2-2] into the tool
holder [2-3] while rotating.
Release the unlocking sleeve.
Check the interlock by pulling the screw
adapter.

8.2 Thread chuck

Inserting
Clean the thread on the drill chuck (ac-
cessory) and on the screw adapter [2-2]
(accessory).
Screw the drill chuck [2-4] onto the adapter
[2-2].
Removing
Pull the unlocking sleeve [2-1] backwards
and remove the drill chuck [2-4] with the
screw adapter [2-2].
If required, fi rst screw the drill chuck [2-4]
from the screw adapter [2-2].

8.3 Tool chuck CENTROTEC

The tool chuck CENTROTEC allows you to
change tools with a CENTROTEC shank in
a matter of seconds.
► Always use a CENTROTEC tool chuck to
clamp CENTROTEC tools.
CAUTION
Risk of cutting injuries when chang-
ing the tool!
► Wear protective gloves!
Attaching the CENTROTEC
Pull the release ring [3-5] forwards.
Attach the tool chuck to the adapter [3-2].
Release the ring [3-5].
Detaching the CENTROTEC
Pull the release ring [3-5] forwards.
Remove the tool chuck.
Changing tools
To fi t or remove a tool with a CENTROTEC
shank, pull back the orange ring [3-6].
While proceeding so, keep turning the tool
until its shank engages in the adapter.
Release the ring [3-5].
9

Practical tips

Do not drill into hidden electri-
cal lines or gas and water pipes.
Check the area to be worked
with a metal detector, for example, before
starting.
For metal, use only fl awless, sharpened
drills; for stone and concrete, only masonry
drills with hard metal inserts.
Always adapt the speed to the material to be
worked and the diameter of the drill. For pre-
cision working with metal and wood, place
the machine in a drill stand (accessory).

10 Maintenance

- The unit should be stored in a dry place
where it is protected against freezing.
- Before any work on the machine itself,
pull the mains plug!
- Always keep the ventilation slots clean.
- The cable may only be replaced in a spe-
cialised electrical workshop qualifi ed to
perform such work.
- Wipe off the accessible plastic parts regu-
larly with a cloth without cleaning agent.
- After heavy use over a long period, the
machine should be taken to a service
location for an inspection and thorough
cleaning.
- Replacing brushes: Worn carbon brush-
es should be replaced by an authorised
customer service organisation.
