Multiplex Antaris Carbotec Handbuch Seite 15

Assembly instructions
Antaris carbotec
Throw
---------------------------------------------------------------------
Aileron servos
Aileron
Flap (Thermal/Speed)
Spoiler (Butterfly)
---------------------------------------------------------------------
Flap servos
Aileron
Flap (Thermal/Speed)
Spoiler (Butterfly)
---------------------------------------------------------------------
Elevator servos
Elevator
Mix to flap (Thermal/Speed)
Mix to Spoiler (Butterfly)
---------------------------------------------------------------------
Rudder servo
Rudder left / right
---------------------------------------------------------------------
Tow hook servo (glider version)
Set complete opening and closing of the hook
---------------------------------------------------------------------
Important note:
Bigger up throws on the flap than recommended are
only useful during inverted flight
Your Antaris carbotec is now ready for the maiden flight!
up (+) / down (-) in mm
Offset ca. 20%
+ 16 / - 8
+ 2 / - 3
+ 21 / 0
Offset ca. 30%
+ 10 / 0
+ 2 / - 4
- 37
up (+) / down (-)
+ 10 / - 10
+- 0 / - 2
- 4
45 / 45
Safety
Safety is the First Commandment when flying any model aircraft. Third
party insurance is a basic essential. If you join a model club suitable
cover will usually be available through the organisation. It is your personal
responsibility to ensure that your insurance is adequate (powered model
aircraft). Make it your job to keep your models and your radio control
system in perfect order at all times. Check the correct charging procedure
for the batteries you are using. Make use of all sensible safety systems
and precautions which are advised for your system. Gather as much in-
formation as you can from our main catalogue, or consult our website
www.multiplex-rc.de.
MULTIPLEX products are produced by knowledgeable model flyers: practi-
cal applications from practical experience. Always fly with a responsible
attitude. You may think that flying low over other people's heads is proof
of your piloting skill, but others know better: the real expert does not need
to prove himself in such ways. Let other pilots know that this is what you
think too. Always fly in such a way that you avoid endangering yourself or
others. Bear in mind that even the best RC system in the world is subject
to outside interference. No matter how many years of accident-free years
of accident-free flying you have under your belt, you have no idea what
will happen in the next minute.
Before every flight it is essential to check that the battery, wings
and tail surfaces are securely fixed. Check every working system!
We - the MULTIPLEX team - wish you many hours of pleasure in building
and flying your model. Happy landings!
EN
15
