Controls

OSM
as follows:
EXIT
CONTROL
CONTROL +/–
PROCEED
RESET
78134441.wpc
Downloaded from www.Manualslib.com
(On-Screen Manager) control buttons on the front of the monitor function
™
Exits the OSM controls.
/ Moves the highlighted area left/right to select one of the controls.
Moves the bar in the + or – direction to increase or decrease
the adjustment.
Enters OSM menu and selects icons at the top of the menu.
Resets the highlighted control to the factory setting.
Brightness/Contrast Controls
Adjusts the overall image and background screen brightness.
Adjusts the image brightness in relation to the background.
Size and Position Controls
Moves the image horizontally (left or right).
Moves the image vertically (up or down).
Increases or decreases the horizontal size of the image.
Increases or decreases the vertical size of the image.
Geometry Controls
The Geometry controls allow you to adjust the curvature or angle of the
sides of your display.
Increases or decreases the curvature of the sides either inward or outward.
Increases or decreases the curvature of the sides either to the left or right.
Increases or decreases the tilt of the sides either to the left or right.
Increases or decreases the top of the screen to be the same as the bottom.
Rotates the entire display clockwise or counterclockwise.
Color Control/AccuColor
Two color presets select the desired color setting. Each color setting is
adjusted at the factory to the stated Kelvin.
Red, Green, Blue: NEC's AccuColor Control System increases or
decreases the monitor's red, green or blue color guns depending upon
which is selected. The change in color will appear on screen and the
direction (increase or decrease) will be shown by the bars.
7
