Specifications cont.
Monitor
Specifications
Picture Tube
Input Signal
Display Colors
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Active Display Area
(Factory Setting)
Active Display Area
(Full Scan)
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
78134441.wpc
Downloaded from www.Manualslib.com
MultiSync
Monitor
Diagonal: 17 inch
Viewable Image Size: 16.0 inch
Radius: 1210 mm
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Analog input: Unlimited number of Colors
Horizontal: 31 kHz to 70 kHz
Vertical: 55 Hz to 120 Hz
640 x 480 @ 60 to 120 Hz
800 x 600 @ 55 to 110 Hz
832 x 624 @ 55 to 105 Hz
1024 x 768 @ 55 to 87 Hz ....................... NEC cites recommended resolution at
1152 x 870 @ 55 to 77 Hz
1280 x 1024 @ 55 to 66 Hz
Horizontal: 310 mm/12.2 inches
Vertical: 232 mm/9.1 inches
325 mm/12.8 inches
243 mm/9.6 inches
AC 100 – 120 V/220-240 V, 50/60 Hz
1.5A @ 100 – 120 V/0.8A @ 220-240V
403 mm (W) x 427 mm (H) x 440 mm (D)
15.9 inches (W) x 16.8 inches (H) x 17.3 inches (D)
16.5 kg
36.4 lbs
Operating Temperature: 0°C to +35°C
Humidity: 30% to 80%
Feet: 0 to 10,000 Feet
Storage Temperature: -20°C to +60°C
Humidity: 10% to 90%
Feet: 0 to 45,000 Feet
NOTE: Technical specifications are subject to change without notice.
12
manuals search engine
® A + ™ Notes
700
90° deflection, 0.28 mm trio dot pitch,
medium short persistence phosphor,
multi-layered, anti-static screen coating,
semi-tint screen, Invar Shadow Mask and
OptiClear ®
Depends on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
85 Hz for optimal display performance.
Dependent upon signal timing used,
and does not include border area.
Dependent upon signal timing used,
and does not include border area.
10
11/20/98, 12:33 PM
screen.
