7.

Disassembly

• After expiry of the fusion time, the electrofusion unit can be switched off
and the fusion cable can be removed.
• After expiry of the waiting time of at least 30 minutes, the compressor can
be switched off.
• Loosen and remove the hose connections, the plunger (only for FRIALEN
spigot saddle SA-XL) and the manometer.
WARNING!
After the disassembly of the plunger, any Vaseline DAB10 residues at the
FRIALEN XL spigot saddle SA-XL are to be thoroughly removed; e.g. us-
ing a suitable PE cleaning agent. Any entrainment of the lubricant into the
fusion areas is to be prevented.
• Protect the equipment and store it again in the transport box.
8. Tapping and commissioning (only for FRIALEN spigot
saddle SA-XL)
Tapping of the FRIALEN XL spigot saddle SA-XL is made using the
FRIATOOLS drilling device FWAB XL.
WARNING!
Please observe the instructions and hazard notes in the operating
instructions of the drilling device FWAB XL!
• The following waiting times are to be observed:
From fusion end to tapping (under
vacuum clamping)
12
Cooling time in minutes for FRIALEN XL
saddle fittings SA-XL
30
Up to pressurisation via the outlet
(CT)
60
