3.
Battery
4.
Speed switch
5.
Torque adjusting ring
6.
Percussion function adjusting ring
7.
Drill chuck
8.
Side handle
2. SAFETY REGULATIONS
The following pictograms appear in these operating instructions:
Carefully read the instructions.
According to the necessary, applicable safety standards and guidelines under
ideal conditions.
Class II charging station – doubly insulated – no grounded plug is required.
Refers to risk of injury, life-threatening danger and possible damage to the device if
the operating instructions are not heeded.
Indicates the presence of an electrical voltage.
Do not dispose of in household waste.
Ni-Cad batteries can be recycled. Drop them off at a disposal center for
chemical wastes, so that they can be recycled or disposed of in an eco-friendly
manner.
Only for use indoors
Never throw the batteries into an open fire
In the event of a disruption, the transformer is not dangerous
Adjustable speed regulator
Wear hearing protection
