Declaration of Conformity

We declare under our sole responsibility that the
product described under "Technical Data" is in
conformity with the following standards or
standardization documents: EN 60745 according
to the provisions of the directives 2004/108/EC,
98/37/EC (until Dec. 28, 2009), 2006/42/EC
(from Dec. 29, 2009 on).
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Dr. Egbert Schneider
Senior Vice President
Engineering
31.07.2007, Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Assembly
Auxiliary Handle (see figure A)
Operate your machine only with the auxiliary
handle 10.
The auxiliary handle 10 can be set to any position
for a secure and low-fatigue working posture.
Turn the bottom part of the auxiliary handle 10 in
counterclockwise direction and swivel the auxil-
iary handle 10 to the desired position. Then
retighten the bottom part of the auxiliary handle
10 by turning in clockwise direction.
Adjusting the Drilling Depth (see figure A)
The required drilling depth X can be set with the
depth stop 11.
Press the button for the depth stop adjustment 9
and insert the depth stop into the auxiliary han-
dle 10.
Pull out the depth stop until the distance be-
tween the tip of the drill bit and the tip of the
depth stop correspond with the desired drilling
depth X.
The knurled surface of the depth stop 11 must
face upward.
Bosch Power Tools
Dr. Eckerhard Strötgen
Head of Product
Certification
Changing the Tool
Before any work on the machine itself, pull
the mains plug.
Keyless Chuck (see figure B)
The drill spindle is locked when the On/Off
switch 5 is not pressed. This makes quick, con-
venient and easy changing of the tool in the drill
chuck possible.
Open the keyless chuck 1 by turning in rotation
direction , until the tool can be inserted. Insert
the tool.
Firmly tighten the collar of the keyless chuck 1 by
hand in rotation direction
tion ("click") is no longer heard. This automati-
cally locks the chuck.
The locking is released again to remove the tool
when the collar is turned in the opposite direc-
tion.
Key Type Drill Chuck (see figure C)
Wear protective gloves when changing the
tool. The drill chuck can become very hot dur-
ing longer work periods.
Open the key type drill chuck 13 by turning until
the tool can be inserted. Insert the tool.
Insert the chuck key 12 into the corresponding
holes of the key type drill chuck 13 and clamp the
tool uniformly.
Screwdriver Tools (see figure D)
When working with screwdriver bits 14, a univer-
sal bit holder 15 should always be used. Use only
screwdriver bits that fit the screw head.
For driving screws, always position the "Drill-
ing/Impact Drilling" selector switch 2 to the
"Drilling" symbol.
Replacing the Drill Chuck
Before any work on the machine itself, pull
the mains plug.
For power tools without spindle lock, the
drill chuck must be replaced by an author-
ised after-sales service agent for Bosch pow-
er tools.
English | 19
until the locking ac-
1 609 929 M17 | (5.9.07)
