TONE control
1
For tuning the tone of input CH 1 to CH 3.
ON/LIMIT indicator
2
Lights up blue as power indicator and red when the signal level is too high; the limiter will reduce
the signal level to protect the speakers.
MIC/LINE selector switches
3
For adjusting the input level of inputs CH 1 and CH 2.
• MIC = for microphones
• LINE = for audio units with line output (e.g. CD player or mixer)
AUX stereo input
4
3.5 mm jack for connecting audio units with line output (e.g. MP3 player or smartphone) to
channel 3. When this jack is connected, the CH 3 RCA jacks will be switched off.
SUB volume control for the subwoofer
5
BALANCE control
6
For adjusting the volume ratio between the left and right satellite speaker.
GAIN control
7
For adjusting the volume of inputs CH 1 to CH 3.
MODE selector switch
8
Selects the signal for the 6.3 mm jack outputs OUT.
• CH2 THRU: the input signal of the CH 2 jacks is available
• REC OUT: the master signal is available
SETUP selector switch
9
Selects the operating mode for the satellite speakers.
• : stereo mode
• : mono mode
CH 1 mono input
10
Balanced combo input (XLR/6.3 mm jack) for channel 1.
CH 2 stereo inputs
11
Balanced combo inputs (XLR/6.3 mm jack) for channel 2.
CH 3 stereo input
12
Unbalanced RCA jacks for channel 3. When the AUX jack is connected, the RCA jacks will be
switched off.
OUT stereo outputs
13
Balanced 6.3 mm jacks with the input signal of the CH 2 jacks or the master signal.
LINK IN/OUT stereo jack
14
Unbalanced 6.3 mm jack to be used as input and output for connection of another audio unit, e.g.
a second ACS-510 active system.
Left speaker connector
15
6.3 mm jack for connecting a satellite speaker.
• stereo mode: left speaker
• mono mode: stacked speakers
Power switch
16
Voltage selector switch
17
Fuse
18
Power input
19
Right speaker connector
20
6.3 mm jack for connecting the right satellite speaker in mono mode.
