ROLLER SHUTTER TRANSMITTER
23
26
25
U
Tophousing
Magnet
Screws
Bottomhousing
Washers
(optional)
(20) Roller shutter transmitter
20
(21) Status LED roller shutter transmitter
(22) Learn button on roller shutter transmitter
(23) Selection jumper 'AND/OR'
21
(24) Battery CR2477
(25) Magnet
22
(26) Roller shutter transmitter
(U) Packer parts
24
Open the casing by lifting the
side with a screwdriver
+
Battery
CR 2477
(Figure 4)
Tophousing
Sensor
Screws
Bottomhousing
Washers(optional)
Positioning Roller Shutter Transmitter (side view)
Transmitter
Magnet
Roller
Shutter
Magnet
Roller shutter closed
open
EN
Roller
Shutter
