Novus J-171 Originalbetriebsanleitung Seite 6

1.
GB
Translation of the original operating instructions
Contents
1. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1. Declaration of Conformity . . . . . . . . . . . . . . . . . .2
1.2. Technical specifications. . . . . . . . . . . . . . . . . . . 10
1.3. Intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.4. Safety precautions and warnings. . . . . . . . . 11
1.5. Pictogram legend . . . . . . . . . . . . . . . . . . . . . . . . 12
1.6. Package contents . . . . . . . . . . . . . . . . . . . . . . . . . 80
2. Normal operation. . . . . . . . . . . . . . . . . . . . . . 80
2.1. Opening magazine . . . . . . . . . . . . . . . . . . . . . . . 80
1.2.
Technical specifications
230V / 50Hz
10 A medium time-lag min.; 16 A medium
time-lag max.
2
Cable 3.5 m long, 2-core (2 x 1 mm )
CEE 7/17 plug, power socket type EF
max. 10 m with core cross-section of 1.5 mm
max. 20 shots/min, S2 30 min
radio-interference-suppressed
We reserve the right to make technical modifications and improvements in the interest of advancing our products.
10 / 88
2.2. Inserting fasteners. . . . . . . . . . . . . . . . . . . . . . . . 81
2.3. Adjusting impact power . . . . . . . . . . . . . . . . . . 81
2.4. Releasing the trigger, firing a shot . . . . . . . . 82
2.6. Multistroke function for staples
and 30 mm nails. . . . . . . . . . . . . . . . . . . . . . . . . . 82
3. Maintenance/Troubleshooting . . . . . . . . . 83
3.1. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 83
3.2. Replacement parts list . . . . . . . . . . . . . . . . .84/85
-10°C to 40°C
243 mm high, 277 mm long, 58 mm wide
Weight:
1690 g
A-weighted sound pressure level
L = 88 dB(A); uncertainty K 2.5 dB(A)
pA pA =
A-weighted sound power level
L = 96 dB(A); uncertainty K 2.5 dB(A)
WA wa =
2
Total vibration value measured
in accordance with EN 60745
Vibration emission value ah = 10.5 m/s
2
uncertainty K = 1.5 m/s
1.
ATTENTION
Read all safety precautions and instructions.
Any failure to follow these safety precautions and
instructions may result in electric shock, fire and/
or severe injuries and consequences.
Keep these operating instruction in a safe place
for future reference.
1.3.
Intended use
This device is used for fastening cardboard, insu-
lation material, textiles, foils, leather, wood and
similar non-brittle materials to wood or wood-like
surfaces. Make sure the workpiece is appropriate
in size.
This device must only be used for the purpose
intended by the manufacturer.
1.4.
Safety precautions and
This device has been manufactured and tested in
accordance with the applicable code of practice. It
left the factory in safe and proper working order.
To maintain this condition and ensure safe oper-
ation, the user must follow the precautions and
warnings given in the operating instructions.
2
;
children's reach.
J-171
working order before it is used.
possible, the device must be taken out of oper-
ation and prevented from being used inadvert-
ently.
rying the device. The device must not be oper-
ated if the power cord is damaged.
age of parts on the device, are not permissible
and will result in the warranty becoming null
and void.
source does not exceed the permissible values
given in the technical specifications.
sons or animals.
Tips and edges of fasteners being inserted
in the magazine, not driven all the way in or
becoming jammed in the magazine after a
malfunction can cause injury.
device should be allowed to cool down after
30 minutes as it is only rated for short-time
duty.
11 / 88
